NHP-10000 Feature Overview

Key Features

High-performance all-in-one solar street light with advanced optics, durable battery system, and smart IoT connectivity for modern urban lighting.

High-Efficiency LED

High-Efficiency LED

Advanced LED technology delivering 10,000 lumens with exceptional energy efficiency and uniform light distribution.

LiFePO4 Battery

LiFePO4 Battery System

Long-lasting lithium iron phosphate battery with 25+ year lifespan and superior performance in all weather conditions.

LiFePO4 Battery

LiFePO4 Battery System

Long-lasting lithium iron phosphate battery with 25+ year lifespan and superior performance in all weather conditions.

Technical Specifications

Solar & Battery System

Lighting Performance

High-efficiency lighting with clear illumination and long lifespan.

Solar & Battery System

Solar & Battery System

Efficient energy storage and smart charging for dependable operation.

Solar & Battery System

Physical & Environmental

Durable design and weather resistance for outdoor conditions.

Advanced Technology

Cutting-edge solar street lighting solution featuring intelligent controls, premium components, and sustainable design for reliable urban illumination.

Smart IoT Control

Smart IoT Control

Intelligent monitoring and control system with remote management capabilities for optimal performance and maintenance.

MPPT Technology

MPPT Technology

Maximum Power Point Tracking ensures optimal solar energy harvesting and battery charging efficiency in all conditions.

Wireless Connectivity

Wireless Connectivity

Advanced wireless communication for seamless integration with smart city infrastructure and real-time monitoring.

NHP-10000 Advanced Technology

Technical specifications and downloads

Lighting

NHP-10000
Light Output 10000-25000LM
LED Chip High bright 5050 (5W/PCS,240LM/W)
CCT 2700-6000K(can be customized)
Life Span 100,000 hours to LM80 specifications
Working Way Motion Sensor / IoT / Time Schedule

Solar Panel

Power of PV module 130W
Life Span 80% power after 25 years

Storage

Battery Capacity 825WH
Life Span 4000 Cycles (10 years)

Charging Controller

Life Span >12 years
Working Mode MPPT
Control Mode Intelligent, activated by sunlight

Environment

Working Temperature -15°C to +70°C
Water Resistance IP65

Mechanical Specifications

Recommended Top diameter of the Pole 76mm
Recommended Pole Height 10m-12m
Net Weight 30Kg
Package Dimension 1580*406*84mm

Lighting

Light Output 8000-15000LM
LED Chip High bright 5050 (5W/PCS,240LM/W)
CCT 2700-6000K(can be customized)
Life Span 100,000 hours to LM80 specifications
Working Way Motion Sensor / IoT / Time Schedule

Solar Panel

Power of PV module 100W
Life Span 80% power after 25 years

Storage

Battery Capacity 550WH
Life Span 4000 Cycles (10 years)

Charging Controller

Life Span >12 years
Working Mode MPPT
Control Mode Intelligent, activated by sunlight

Environment

Working Temperature -15°C to +70°C
Water Resistance IP65

Mechanical Specifications

Recommended Top diameter of the Pole 76mm
Recommended Pole Height 8m-10m
Net Weight 24.5Kg
Package Dimension 1206*406*84mm

Lighting

Light Output 5000-10000LM
LED Chip High bright 5050 (5W/PCS,240LM/W)
CCT 2700-6000K(can be customized)
Life Span 100,000 hours to LM80 specifications
Working Way Motion Sensor / IoT / Time Schedule

Solar Panel

Power of PV module 70W
Life Span 80% power after 25 years

Storage

Battery Capacity 390WH
Life Span 4000 Cycles (10 years)

Charging Controller

Life Span >12 years
Working Mode MPPT
Control Mode Intelligent, activated by sunlight

Environment

Working Temperature -15°C to +70°C
Water Resistance IP65

Mechanical Specifications

Recommended Top diameter of the Pole 76mm
Recommended Pole Height 6m-8m
Net Weight 19Kg
Package Dimension 822*406*84mm

Lighting

Light Output 3000-5000LM
LED Chip High bright 5050 (5W/PCS,240LM/W)
CCT 2700-6000K(can be customized)
Life Span 100,000 hours to LM80 specifications
Working Way Motion Sensor / IoT / Time Schedule

Solar Panel

Power of PV module 40W
Life Span 80% power after 25 years

Storage

Battery Capacity 280WH
Life Span 4000 Cycles (10 years)

Charging Controller

Life Span >12 years
Working Mode MPPT
Control Mode Intelligent, activated by sunlight

Environment

Working Temperature -15°C to +70°C
Water Resistance IP65

Mechanical Specifications

Recommended Top diameter of the Pole 60mm
Recommended Pole Height 3m-6m
Net Weight 11.5Kg
Package Dimension 457*406*84mm
NHP-10000 Feature Overview

Why Choose NHP-10000?

Innovative design elements that enhance functionality and overall efficiency: :

High-Efficiency LED

High-Efficiency LED

Advanced LED technology delivering 10,000 lumens with exceptional energy efficiency and uniform light distribution.

LiFePO4 Battery

LiFePO4 Battery System

Long-lasting lithium iron phosphate battery with 25+ year lifespan and superior performance in all weather conditions.

LiFePO4 Battery

LiFePO4 Battery System

Long-lasting lithium iron phosphate battery with 25+ year lifespan and superior performance in all weather conditions.

Installation area lighting solution

Solar Street Lighting

Solar Street Lighting

Shared Pathways

Shared Pathways

Solar Park Lighting

Solar Park Lighting

Solar Car Park Lighting

Solar Car Park Lighting
